| Parameter | Details |
|---|---|
| Model | U2412 TRUE FLAT BED |
| Print Technology | LED UV Flatbed Printing |
| Print Size | 2.5 × 1.3 m (8 × 4 ft) |
| Head Model | Ricoh G5, Automatic Heating |
| Head Quantity | 2–8 pcs |
| Head Board | UMC |
| Print Direction | Unidirectional / Bidirectional |
| Print Height | Automatic Height Measurement |
| Head Cleaning System | Positive Pressure Clean, Servo Motor & Lead Screw |
| Print Speed | Production: 20–30 sqm/h Quality: 15–20 sqm/h High Resolution: 10–15 sqm/h |
| Ink Type | UV Ink (Ricoh Certified) |
| Color Set | CMYK + LM + LC + W + V |
| Ink Cartridge Volume | 3 L |
| Ink Supply System | Independent Dual Negative Pressure Ink Supply |
| Drying Type | Imported LED Lamp Curing |
| White Ink Stirring | Standard Configuration |
| White Ink Circulation | Standard Configuration |
| Media Type | Acrylic / Aluminum / Ceramic / Foam Board / Glass / Cardboard / Sunboard |
| Max Media Thickness | 100 mm (Customizable) |
| RIP Software | Photo Print / ONYX |
| Interface | USB 3.0 |
| Color Control | ICC Standard, Curve & Density Adjustment |
| Image Format | TIFF / JPEG / POSTSCRIPT3 / PDF |
| Power Supply | AC 220V, 50/60Hz |
| UV Lamp Power | 2.5 kW |
| Noise Level | Standby <32 dB, Working <65 dB |
| Lamp Life | LED curing, up to 50,000 hours |
| Cooling System | Water Cooling |
| Packing Size | 4.7 × 2.3 × 1.65 m |
| Packing Weight | 1400 kg |
